Basic Information
Movement
Linear Displacement
Production Process
Injection
Product Introduction
🚀 Key Features
Genuine Absolute Position System
Ideal for high-dynamic control loops
Ultra-high precision (Resolution up to 0.1 μm)
Maximum measuring length: 16.4 m
Measuring speed: 7 m/s
Protocols: SSI / BiSS / Tamagawa / Modbus
Rugged design with IP67 protection
Drag chain cable (20+ million cycles)
Smart error diagnostics with real-time alerts
Technical Parameters
| Description |
Parameter |
Remark |
| Working Voltage | 5V | ±5% |
| Operating Current | ±150mA Max | 25ºC Room Temp |
| Resolution | 0.1 - 100 um | Customizable |
| Output Signal | BISS-C, SSI, MODEBUS-RTU | - |
| Positioning Accuracy | ≤30um | - |
| Repeatability | ≤±1um | - |
| Measuring Length | 16.4 Meters Max | - |
| Protection Rating | IP67 | - |
| Operating Temperature | -5 ... 70ºC | - |
Company Profile
Specializing in the R&D, production, and sales of precision motion control solutions, including magnetic & optical grating encoders, position indicators, and micro servo drivers. We design high-performance, ultra-reliable sensors for critical measurement, serving advanced industries like semiconductors, lithium batteries, industrial robotics, and medical equipment.
Our Factory & Advantages
Exhibition & Shipping
Frequently Asked Questions
How soon can I expect a response?
We'll get back to you within 12 hours guaranteed.
Do you offer samples?
Yes! We provide free sample testing so you can evaluate our products risk-free.
What's the quality standard of your encoders?
All our encoders are ISO 9001 and CE certified. We are happy to share test reports for your review.
How competitive are your prices?
Unbeatable value: Premium quality at 30%+ savings vs. Western brands with identical specs.
What is the typical delivery time?
Less than 100 pcs: 7 days; Less than 1,000 pcs: 20 days.
What is covered under warranty?
A 1-year factory warranty covers repairs or replacements for any non-human-caused defects.
